Central Station Plus

The PreSonus Central Station Plus is the perfect monitoring “hub” for your studio! With five stereo inputs (two digital and three analog) and three outputs, each providing the purest possible signal path, the Central Station is where all your audio sources can converge for high quality monitoring. And with the included CSR-1 remote control, you’ll never need to leave your mix position to manage your monitoring.

With Central Station, you can easily switch between three sets of stereo, analog input sources. Two stereo S/PDIF digital sources connect via one coax and one Toslink optical port. You can audition these sources with up to three pairs of speakers, with individual trim pots for each speaker – recessed to avoid accidents.

You also get a pair of line-level main outputs, a pair of line-level cue outputs, and two screaming-loud headphone amplifiers with individual level controls. And because Central Station is a 1U rack-mount device, with only one multi-conductor cable running to the remote control on your desktop, all of the cabling is in the back of your rack, where it belongs.

Features:

• Included CSR-1 remote control brings monitor management to your desktop
• S/PDIF coax or TOSlink digital input
• Two balanced TRS jacks and two RCA inputs with trim control
• D/A conversion up to 24-bit/192kHz
• Dual fast-acting 30-segment digital LED meters
• Omnidirectional condenser microphone routed through CUE outputs
• When talkback is used, the cue mix is automatically dimmed
• Two headphone outputs, MUTE, DIM, INPUT select, CUE select and OUTPUT select
• Optional remote control for talkback, mute, dim, and I/O selection
