BiG [Studio]

BiG [Studio] spectacularly enlarges the stereo image and opens up new creative ways of sound shaping.

BiG [Studio] expands the possibilities of sound shaping with a new tube circuit. The Tube Harmonics control refines the harmonic spectrum of every signal, making it more vivid, detailed and increased in size – bigger than life! Visually, BiG [Studio] sports the black design of the SPL Studio series. The internal audio voltage of +/-18V ensures great sound!

Features:

• Stereo image processor and tube harmonics generator
• Range control selects frequency range
• Stage control moves selected frequency range forward or backward in the soundstage
• Harmonics button activates harmonics generation in the tube circuit
• Tube Harmonics control adjusts the intensity of the tube harmonics
• Bigness control sets overall processing intensity
• Bass button switches in a passive bass boost
• Bypass toggle for easy wet/dry comparison
• Frequency response (-3dB): 10Hz–200kHz
• THD+N (0dBu, 10Hz–22kHz): 0.0035%
• Noise (A-weighted): -97.5dBu
• Dynamic range: 120dB
• Bass frequency: 42Hz; Bass boost: 2dB
• Harmonics frequency: 6kHz; Harmonics boost (max.): 9dB
• I/O: gold-plated Neutrik XLRs and TRS jacks (connected in parallel)
• Internal linear power supply with a shielded toroidal transformer
• Mains (selectable): 115VAC/60Hz, 230VAC/50Hz
• Crafted in SPL’s production facility in Niederkrüchten, Germany
