1248

32 x 34 IO with 4 mic in 8×12 TRS 48ch mixing DSP and AVB TSN networking

SKU motu-1248BrandMOTUCategory
User Manual
1Year Warranty
Ships in 1-2 daysShips in 1-2 days

159,499 (incl. GST)

- +

You get 32 inputs and 34 outputs, including a flexible 8 x 12 analog section. Four stellar MOTU preamps provide clean and clear amplification, and extremely high-speed Thunderbolt connectivity makes latency a total nonissue. Onboard the 1248 you’ll find a powerful DSP mixer complete with effects, EQ, and dynamics. MOTU AVB Ethernet lets you network multiple interfaces to your 1248, and advanced capabilities even let you use it as a standalone, iPad-controlled digital mixer.

Features:

  • A fantastic 32-in/34-out hybrid audio interface for studio and live sound applications
  • 4 pristine microphone preamplifiers offer clear and transparent sound of any kind of microphone
  • ADAT optical and S/PDIF digital I/O let you expand your system with additional gear
  • Choose from ultra-low-latency Thunderbolt, high-speed USB 2.0, or iPad/iOS (w/ Camera Connection Kit) connectivity
  • Onboard 32-bit floating point DSP-driven digital mixer with EQ, dynamics, and effects provides latency-free routing
  • Hook up a wireless router and take complete control of the onboard mixer from your iOS device – no computer needed!
  • MOTU’s AVB audio networking lets you easily expand your system and additional AVB equipped audio interfaces
  • Create an AVB network via optional AVB Switches for support for up to five compatible interfaces
Computer Connection Thunderbolt 2, USB 2.0
Simultaneous I/O 32 x 34
A/D Resolution 24-bit/192kHz
Built-in DSP/FX Yes
Audio Input Types 4 x XLR, 8 x 1/4" TRS, 2 x 1/4" (hi-Z)
Audio Output Types 8 x 1/4" (line out), 2 x 1/4" (main out), 2 x 1/4" (monitor out), 2 x 1/4" (headphones)
Digital Input Types 2 x Optical (ADAT, SMUX), 1 x Coaxial (S/PDIF)
Digital Output Types 2 x Optical (ADAT, SMUX), 1 x Coaxial (S/PDIF)
No. of Mic Preamps 04
Phantom Power Yes
MIDI I/O No
Bus Powered No
Rack Unit 1U
H x W x D 1.75" x 19" x 7"
Weight 2.04kg
Any other features? Clock I/O : In, Out/Thru. Data I/O: Ethernet
  • 1 x audio interface
  • 1 x  USB cable
  • 1 x  power cord
  • 1 x  manual
  • 1 x Product registration card
